| PartNumber | HT121WX2-211 |
| Značka | HYDIS |
| Velikost | 12.1 |
| aplikace | PAD |
| Rozlišení | 1280×800 |
| Složení | LCM |
| Jas | 200 |
| CR | |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | HYDIS |
| panelový model | HT121WX2-211 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 12.1 inch |
| rozlišení | 1280(RGB)×800 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 261.12×163.2 mm |
| obrys | 276.8×180 mm |
| povrch | |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | |
| úhel pohledu | 45/45/20/40 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 6-bit) |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PAD |
| A121EW02 V0 | AUO | 12.1 | 1280×800 |
| G121STN01.0 | AUO | 12.1 | 800×600 |
| HSD121PS11-A | HannStar | 12.1 | 800×600 |
| HT121WX2-210 | HYDIS | 12.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| LQ121S1LG73 | SHARP | 12.1 | 800×600 |
| LQ121S1LG81 | SHARP | 12.1 | 800×600 |
| LT121DEVQB00 | TOSHIBA | 12.1 | 1280×800 |
| LTD121EX1S | TOSHIBA | 12.1 | 1280×768 |
| NL8060BC31-42D | NLT | 12.1 | 800×600 |
| B080UAN01.4 | AUO | 8.0 | 1200×1920 |
| CLAA070WP03XG | CPT | 7.0 | 800×1280 |
| LD080WX2-SMN1 | LG Display | 8.0 | 800×1280 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LP101WH4-SLAF | LG Display | 10.1 | 1366×768 |
| LTL097QL01-A01 | Samsung | 9.7 | 2048×1536 |
| LTN101AL03-001 | Samsung | 10.1 | 1280×800 |
| LTN121AP06-301 | Samsung | 12.1 | 1280×800 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TM080VDSP01 | Tianma | 8.0 | 1200×1920 |
