| PartNumber | 990000738A |
| Značka | Innolux |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 350 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Serial RGB |
| značka panelu | CHIMEI INNOLUX |
| panelový model | 990000738A |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 76.84×43.2 mm |
| obrys | 89.5×51.76×2.9 mm |
| povrch | Glare (Haze 0%) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 5/11 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/60/50 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 4S1PWLEDWithout Driver |
| signálové rozhraní | Serial RGB (8-bit) + SPI, 39 pins |
| vstupní napětí | 3.1V (Typ.) |
| aplikace | DSC |
| 990000006 | TPO | 3.0 | 320×240 |
| 990000270 | TPO | 2.5 | 320×240 |
| 990000475 | TPO | 4.3 | 800×480 |
| 990000475P | TPO | 4.3 | 800×480 |
| 990000553 | TPO | 3.5 | 320×240 |
| 990000738 | TPO | 3.5 | 320×240 |
| 990000738A | Innolux | 3.5 | 320×240 |
| 990000881 | TPO | 3.0 | 960×480(dot) |
| 990001086 | Innolux | 3.0 | |
| NL2432HC22-25E | NLT | 3.5 | 240×320 |
| A015AN04 V6 | AUO | 1.5 | 280×220 |
| A025DN01 V3 | AUO | 2.5 | 320×240 |
| A030DN01 V0 | AUO | 3.0 | 320×240 |
| A035QN01 V4 | AUO | 3.5 | 320×240 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| TD015THEB2 | TPO | 1.5 | 480×240 |
| TD024THEB2 | TPO | 2.4 | 480×240 |
| TD025THEEA | TPO | 2.5 | 640×240 |
| TM027CDH19 | Tianma | 2.7 | 320×240 |
| TM035KDH16-09 | Tianma | 3.5 | 320×240 |
