| PartNumber | AMS369FG03-002 |
| Značka | Samsung |
| Velikost | 3.7 |
| aplikace | MPH |
| Rozlišení | 480×800 |
| Složení | OLED |
| Jas | 250 |
| CR | 10000:1 |
| Barvy | 262K |
| Podsvícení | self |
| Rozhraní | TTL |
| značka panelu | SAMSUNG |
| panelový model | AMS369FG03-002 |
| typ panelu | AM-OLED , OLED |
| velikost panelu | 3.7 inch |
| rozlišení | 480RG(BG)×800 , WVGA |
| aktivní oblast | 48.24×80.4 mm |
| obrys | 53.94×90 mm |
| povrch | Hard coating (2H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 10000 : 1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE1931106% |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥200)(L/R/U/D) |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit) + SPI, 40 pins |
| vstupní napětí | 2.6/2.8/2.8V (Typ.)(IOVCC/VCC/VCI) |
| aplikace | MPH |
