| PartNumber | LS037V7DD06 |
| Značka | SHARP |
| Velikost | 3.7 |
| aplikace | MPH |
| Rozlišení | 480×640 |
| Složení | LCM |
| Jas | 100 |
| CR | 100:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LS037V7DD06 |
| typ panelu | CG-Silicon , LCM |
| velikost panelu | 3.7 inch |
| rozlišení | 480(RGB)×640 , VGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 56.16×74.88 mm |
| obrys | 65×90 mm |
| povrch | |
| jas | 100 cd/m² (Typ.) |
| kontrastní poměr | 100:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 30/50 (Typ.)(Tr/Td) |
| úhel pohledu | 40/40/40/40 (Typ.)(CR≥2)(L/R/U/D) |
| typ lampy | WLED |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 51 pins |
| vstupní napětí | 5.0/3.3/8.0/-4.0/-8.0V (Typ.)(VSHA/VSHD/VDD/VSSD/GVSS) |
| aplikace | MPH |
