| PartNumber | AT043TN13 TP |
| Značka | Innolux |
| Velikost | 4.3 |
| aplikace | PND |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 280 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | INNOLUX |
| panelový model | AT043TN13 TP |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.3 inch |
| rozlišení | 480(RGB)×272 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 95.04×53.856 mm |
| obrys | 105.5×67.2×5.3 mm |
| povrch | Hard coating (3H) |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/50/70 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S2PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit), 40 pins |
| vstupní napětí | (2.5/3.3)/5.0V (Typ.)(VDD/AVDD) |
| aplikace | PND |
| 43WQW3H | SII | 4.3 | 480×272 |
| AM480272H3TMQW-W2H | AMPIRE | 4.3 | 480×272 |
| AT043TN13 | Innolux | 4.3 | 480×272 |
| AT043TN13 TP | Innolux | 4.3 | 480×272 |
| AT043TN24 V.1 | Innolux | 4.3 | 480×272 |
| AT043TN24 V.7 | Innolux | 4.3 | 480×272 |
| AT043TN25 V.1 | Innolux | 4.3 | 480×272 |
| AT043TN25 V.2 | Innolux | 4.3 | 480×272 |
| LH430WV1-SD01 | LG Display | 4.3 | 480×800 |
| TX11D101VM0EAA | KOE | 4.3 | 480×800 |
| A050FW03 V2 | AUO | 5.0 | 480×272 |
| ED043CA-01D | Innolux | 4.3 | 480×272 |
| EJ050NA-01D | Innolux | 5.0 | 800×480 |
| LMS430HF41-004 | Samsung | 4.3 | 480×272 |
| LMS500HF04-002 | Samsung | 5.0 | 480×272 |
| LQ035Q1DG04 | SHARP | 3.5 | 320×240 |
| LQ043T3DX04 | SHARP | 4.3 | 480×272 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| LTE430WQ-F0B | Samsung | 4.3 | 480×272 |
| PT035TN01 V.3 | Innolux | 3.5 | 320×240 |
