| PartNumber | BT055FWM-N00 |
| Značka | BOE |
| Velikost | 5.5 |
| aplikace | MPH |
| Rozlišení | 480×854 |
| Složení | LCM |
| Jas | 300 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | BOE |
| panelový model | BT055FWM-N00 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.5 inch |
| rozlišení | 480(RGB)×854 , FWVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 68.04×121.05 mm |
| obrys | 72.34×130.86×2.3 mm |
| povrch | Antiglare |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 25 pins |
| vstupní napětí | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikace | MPH |
