| PartNumber | BTL454885-W698L |
| Značka | BOE |
| Velikost | 4.5 |
| aplikace | MPH |
| Rozlišení | 480×854 |
| Složení | LCM |
| Jas | 350 |
| CR | 700:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | BOE |
| panelový model | BTL454885-W698L |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.5 inch |
| rozlišení | 480(RGB)×854 , FWVGA |
| zobrazovací mód | ADS, Normally Black, Transmissive |
| aktivní oblast | 55.44×98.637 mm |
| obrys | 59.9×108.88 mm |
| povrch | Glare (Haze 0%), Hard coating |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 700:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193168% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S1PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 24 pins |
| vstupní napětí | 1.8/2.85V (Typ.)(IOVCC/VCI) |
| aplikace | MPH |
