| PartNumber | ACX565AKM-7 |
| Značka | SONY |
| Velikost | 3.5 |
| aplikace | MPH |
| Rozlišení | 800×480 |
| Složení | LCM |
| Jas | 275 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | CDP |
| značka panelu | SONY |
| panelový model | ACX565AKM-7 |
| typ panelu | LTPS TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 800(RGB)×480 , WVGA |
| zobrazovací mód | VSPEC II, Normally Black, Transflective |
| aktivní oblast | 76.8×46.08 mm |
| obrys | 87.9×52.18 mm |
| povrch | |
| jas | 275 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.)(Transmissive)24:1 (Typ.)(Reflective) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 12/7 (Typ.)(Tr/Td) |
| úhel pohledu | |
| frekvence | 60Hz |
| typ lampy | 3S2PWLEDWithout Driver |
| signálové rozhraní | CDP (2 Lane) + SPI, 24 pins |
| vstupní napětí | 1.8/2.75V (Typ.)(VDDI/VDD) |
| aplikace | MPH |
| 35QVW1T | SII | 3.5 | 320×240 |
| 35WVF0H | SII | 3.5 | 480×800 |
| A035CN02 V1 | AUO | 3.5 | 480×234 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| ACX567AKM-7 | SONY | 3.2 | 320×480 |
| AM-320240LATNQW-00H-F | AMPIRE | 3.5 | 320×240 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| T-55343GD035JU-LW-AFN | Kyocera | 3.5 | 320×240 |
| TD035SHED1 | TPO | 3.5 | 480×640 |
| TM035KDH05 | Tianma | 3.5 | 320×240 |
| ACX565AKM-7 | SONY | 3.5 | 800×480 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| DLC0350TZG | Other | 3.5 | 240×320 |
| ET028002DHU | EDT | 2.8 | 240×320 |
| LH400WV3-SD05 | LG Display | 4.0 | 480×800 |
| LTM024DC9B | TOSHIBA | 2.4 | 240×320 |
| LTM030DH60 | TOSHIBA | 3.0 | 240×427 |
| OEL9M0053-Y-E | Other | 1.6 | 128×64 |
| PJ045IC-01F | Innolux | 4.5 | 720×1280 |
| TM030LBHT1 | Tianma | 3.0 | 240×400 |
