| PartNumber | C070FW01 V0 |
| Značka | AUO |
| Velikost | 7.0 |
| aplikace | CNS |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | 500 |
| CR | 300:1 |
| Barvy | |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | AUO |
| panelový model | C070FW01 V0 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 154.08×86.58 mm |
| obrys | 164.9×100 mm |
| povrch | Antiglare (Haze 25%) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 300:1 (Typ.) |
| zobrazit barvy | , CIE193148% |
| Doba odezvy | 12/18 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/40/60 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 26 pins |
| vstupní napětí | 3.3/5/15/-10V (Typ.)(VCC/AVDD/VGH/VGL) |
| aplikace | CNS |
| B070ATN01.0 | AUO | 7.0 | 1024×600 |
| C070FW01 V0 | AUO | 7.0 | 480×234 |
| C070FW02 V0 | AUO | 7.0 | 480×234 |
| C070FW02 V2 | AUO | 7.0 | 480×234 |
| C070FW03 V0 | AUO | 7.0 | 480×234 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| HSD070PFW3-B02 | HannStar | 7.0 | 1024×600 |
| LB070WQ7-TD02 | LG Display | 7.0 | 480×234 |
| LD070WS2-SL07 | LG Display | 7.0 | 1024×600 |
| N070ICG-LD3 | Innolux | 7.0 | 1280×800 |
| C061FW01 V0 | AUO | 6.1 | 480×234 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| LB080WV6-TA03 | LG Display | 8.0 | 800×480 |
| LQ042B5DG02 | SHARP | 4.2 | 400×96 |
| LQ088H9DZ03 | SHARP | 8.8 | 640×240 |
| LTA065B0F0F | TOSHIBA | 6.5 | 800×480 |
| PD050VX6 | E Ink | 5.0 | 640×480 |
| PM061WX1 | E Ink | 6.1 | 800×480 |
| PM070WT2 | E Ink | 7.0 | 800×480 |
