| PartNumber | CLAA080WQ02 XN |
| Značka | CPT |
| Velikost | 8.0 |
| aplikace | PAD |
| Rozlišení | 800×1280 |
| Složení | LCM |
| Jas | 400 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | CPT |
| panelový model | CLAA080WQ02 XN |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.0 inch |
| rozlišení | 800(RGB)×1280 , WXGA |
| zobrazovací mód | HFFS, Normally Black, Transmissive |
| aktivní oblast | 107.64×172.224 mm |
| obrys | 114.6×184.1×3.65 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S7PWLEDWithout Driver |
| signálové rozhraní | MIPI (4 data lanes), 34 pins |
| vstupní napětí | 1.8/3.3V (Typ.)(VCCI/VDDI) |
| aplikace | PAD |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| CLAA080LJ01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA12 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ02 XN | CPT | 8.0 | 800×1280 |
| CLAA080XA03BW | CPT | 8.0 | 1024×768 |
| B101EAN01.7 | AUO | 10.1 | 1280×800 |
| B101EVN06.1 | AUO | 10.1 | 1280×800 |
| B101EVT03.1 | AUO | 10.1 | 1280×800 |
| CLAA101WH12 LE | CPT | 10.1 | 1280×800 |
| HSD101PHW1-A00 | HannStar | 10.1 | 1366×768 |
| HSD101PWW1-H00 | HannStar | 10.1 | 1280×800 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| N080ICE-GB0 Rev.C1 | Innolux | 8.0 | 800×1280 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
| TPF0702001N | JDI | 7.0 | 1200×1920 |
