| PartNumber | CLAA088WA01XN |
| Značka | CPT |
| Velikost | 8.8 |
| aplikace | CNS |
| Rozlišení | 1280×480 |
| Složení | LCM |
| Jas | 500 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CPT |
| panelový model | CLAA088WA01XN |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.8 inch |
| rozlišení | 1280(RGB)×480 , DVGA |
| zobrazovací mód | HFFS, Normally Black, Transmissive |
| aktivní oblast | 209.28×78.48 mm |
| obrys | 229.6×97.3×6.3 mm |
| povrch | Antiglare (Haze 25%) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S14PWLEDWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 60 pins |
| vstupní napětí | 3.3/13.0/20/-6.0V (Typ.)(DVDD/AVDD/IGH/IGL) |
| aplikace | CNS |
