| PartNumber | G121S1-L01 |
| Značka | Innolux |
| Velikost | 12.1 |
| aplikace | CNS |
| Rozlišení | 800×600 |
| Složení | LCM |
| Jas | 450 |
| CR | 1000:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | CMO |
| panelový model | G121S1-L01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 12.1 inch |
| rozlišení | 800(RGB)×600 , SVGA |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 246×184.5 mm |
| obrys | 260.5×204×12.7 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 13/12 (Typ.)(Tr/Td) |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | LVDS (1 ch, 6-bit), 20 pins |
| vstupní napětí | 3.3/5.0V (Typ.) |
| aplikace | CNS |
