| PartNumber | LB070WQ5-TD01 |
| Značka | LG Display |
| Velikost | 7.0 |
| aplikace | CNS |
| Rozlišení | 480×240 |
| Složení | LCM |
| Jas | 500 |
| CR | 400:1 |
| Barvy | 262K |
| Podsvícení | CCFL |
| Rozhraní | TTL |
| značka panelu | LG.Philips LCD |
| panelový model | LB070WQ5-TD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 480(RGB)×240 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 155.952×82.8 mm |
| obrys | 168.8×93.5 mm |
| povrch | Antiglare |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193145% |
| Doba odezvy | 10/20 (Typ.)(Tr/Td) |
| úhel pohledu | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | CCFL |
| signálové rozhraní | TTL (1 ch, 6-bit), 40 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | CNS |
