| PartNumber | G170J1-LE1 |
| Značka | Innolux |
| Velikost | 17.0 |
| aplikace | IA |
| Rozlišení | 1920×1200 |
| Složení | LCM |
| Jas | 600 |
| CR | 2000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | INNOLUX |
| panelový model | G170J1-LE1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1920(RGB)×1200 , WUXGA |
| zobrazovací mód | Super MVA, Normally Black, Transmissive |
| aktivní oblast | 365.76×228.6 mm |
| obrys | 386.8×250.8×19 mm |
| povrch | Glare (Haze 0%) |
| jas | 600 cd/m² (Typ.) |
| kontrastní poměr | 2000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 20/9 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | IA |
