| PartNumber | G185XW01 V1 |
| Značka | AUO |
| Velikost | 18.5 |
| aplikace | IA |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 300 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | AUO |
| panelový model | G185XW01 V1 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 18.5 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 409.8×230.4 mm |
| obrys | 430.4×254.6×16.9 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 300 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193168% |
| Doba odezvy | 3.5/1.5 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | IA |
| G185HAN01.0 | AUO | 18.5 | 1920×1080 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| G185XW01 V2 | AUO | 18.5 | 1366×768 |
| HT185WX1-100 | BOE | 18.5 | 1366×768 |
| LC185EXE-TEA1 | LG Display | 18.5 | 1366×768 |
| LC190WH1-TLC1 | LG Display | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| M185XW01 V8 | AUO | 18.5 | 1366×768 |
| M185XW01 VF | AUO | 18.5 | 1366×768 |
| EL320.240-FA3 CC | Lumineq | 4.9 | 320×240 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| LM64P10 | SHARP | 7.2 | 640×480 |
| LQ150X1LW71N | SHARP | 15.0 | 1024×768 |
| LQ150X1LW96 | SHARP | 15.0 | 1024×768 |
| LTD104C11U | TOSHIBA | 10.4 | 640×480 |
| M190EG01 V0 | AUO | 19.0 | 1280×1024 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| RGS32256064WH002 | RiTdisplay | 3.2 | 256×64 |
| TM320240EGFWVSWD | Tianma | 5.7 | 320×240 |
