| PartNumber | H572DAN01.2 |
| Značka | AUO |
| Velikost | 5.7 |
| aplikace | MPH |
| Rozlišení | 1080×1920 |
| Složení | CELL |
| Jas | 0 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | MIPI |
| značka panelu | AUO |
| panelový model | H572DAN01.2 |
| typ panelu | LTPS TFT-LCD , CELL |
| velikost panelu | 5.7 inch |
| rozlišení | 1080(RGB)×1920 , FHD |
| zobrazovací mód | AHVA, Normally Black, Transmissive |
| aktivní oblast | 71.28×126.72 mm |
| obrys | 73.68×133.27 mm |
| povrch | Hard coating |
| hloubka skla | 0.15+0.15 mm |
| propustnost | 4.8% (Typ.)(with Polarizer) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 20/15 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥100)(L/R/U/D) |
| řidič ic | COG Built-in R63311 |
| aplikace | MPH |
