| PartNumber | LS035Y8DX02A |
| Značka | SHARP |
| Velikost | 3.5 |
| aplikace | MPH |
| Rozlišení | 480×800 |
| Složení | LCM |
| Jas | 500 |
| CR | 500:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LS035Y8DX02A |
| typ panelu | CG-Silicon , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 480(RGB)×800 , WVGA |
| zobrazovací mód | ASV, Normally Black, Transflective |
| aktivní oblast | 45.36×75.6 mm |
| obrys | 51.16×86.45 mm |
| povrch | |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 500:1 (Typ.)(Transmissive)10:1 (Typ.)(Reflective) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 11/24 (Typ.)(Tr/Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 7S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit) + SPI, 50 pins |
| vstupní napětí | 1.8/2.8V (Typ.)(VDDIO/VCC) |
| aplikace | MPH |
