| PartNumber | KCB6448BSTT-X5 |
| Značka | Kyocera |
| Velikost | 10.4 |
| aplikace | IA |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 130 |
| CR | 20:1 |
| Barvy | Color |
| Podsvícení | CCFL |
| Rozhraní | Parallel Data |
| značka panelu | Kyocera |
| panelový model | KCB6448BSTT-X5 |
| typ panelu | CSTN-LCD , LCM |
| velikost panelu | 10.4 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | STN, Normally Black, Transmissive |
| aktivní oblast | 211.2×158.4 mm |
| obrys | 264×183 mm |
| povrch | Antiglare |
| jas | 130 cd/m² (Typ.) |
| kontrastní poměr | 20:1 (Typ.) |
| zobrazit barvy | Color , CIE193140% |
| Doba odezvy | 160/80 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/35/20 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 75Hz |
| typ lampy | 2 pcsCCFLWithout Driver |
| signálové rozhraní | Parallel Data (2ch, 8-bit), 29 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | IA |
