| PartNumber | KHB065HV1BD-M10 |
| Značka | Kyocera |
| Velikost | 6.5 |
| aplikace | IA |
| Rozlišení | 640×240 |
| Složení | LCM |
| Jas | |
| CR | 15:1 |
| Barvy | Color |
| Podsvícení | CCFL |
| Rozhraní | Parallel Data |
| značka panelu | Kyocera |
| panelový model | KHB065HV1BD-M10 |
| typ panelu | CSTN-LCD , LCM |
| velikost panelu | 6.5 inch |
| rozlišení | 640(RGB)×240 , HVGA |
| zobrazovací mód | STN, Normally Black, Transflective |
| aktivní oblast | 153.58×57.58 mm |
| povrch | Glare (Haze 0%) |
| jas | |
| kontrastní poměr | 15:1 (Typ.)(Transmissive)5:1 (Typ.)(Reflective) |
| zobrazit barvy | Color |
| Doba odezvy | 200/150 (Typ.)(Tr/Td) |
| úhel pohledu | 50/50/30/40 (Typ.)(CR≥2)(L/R/U/D) |
| typ lampy | 1 pcsCCFL |
| signálové rozhraní | Parallel Data (8-bit), 18 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
