PartNumber | NL3224BC35-22 |
Značka | NLT |
Velikost | 5.5 |
aplikace | IA |
Rozlišení | 320×240 |
Složení | LCM |
Jas | 750 |
CR | 500:1 |
Barvy | 262K |
Podsvícení | CCFL |
Rozhraní | TTL |
značka panelu | NEC |
panelový model | NL3224BC35-22 |
typ panelu | a-Si TFT-LCD , LCM |
velikost panelu | 5.5 inch |
rozlišení | 320(RGB)×240 , QVGA |
zobrazovací mód | TN, Normally White, Transmissive |
aktivní oblast | 111.36×83.52 mm |
obrys | 134×104.5 mm |
povrch | Clear, Hard coating (2H), Antireflection |
jas | 750 cd/m² (Typ.) |
kontrastní poměr | 500:1 (Typ.) |
zobrazit barvy | 262K (6-bit), CIE193150% |
Doba odezvy | 5/25 (Typ.)(Tr/Td) |
úhel pohledu | 55/55/50/40 (Typ.)(CR≥10)(L/R/U/D) |
frekvence | 60Hz |
typ lampy | 2 pcsCCFLWithout Driver |
signálové rozhraní | CMOS (1 ch, 6-bit), 33 pins |
vstupní napětí | 3.3/5.0V (Typ.)(VCC) |
aplikace | IA |
