| PartNumber | PW050XS3 |
| Značka | E Ink |
| Velikost | 5.0 |
| aplikace | CNS |
| Rozlišení | 320×220 |
| Složení | LCM |
| Jas | 350 |
| CR | 350:1 |
| Barvy | Full color |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | PVI |
| panelový model | PW050XS3 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 320(RGB)×220 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 112.5×60.5 mm |
| obrys | 125.4×74×6.5 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | Full color |
| Doba odezvy | 15/30 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/35 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 30 pins |
| vstupní napětí | 3.3/3.3/5.0/15.0/-12.0V (Typ.)(VCC/VDD1/VDD2/VGH/VGL) |
| aplikace | CNS |
