| PartNumber | LH300WQ1-ED01 |
| Značka | LG Display |
| Velikost | 3.0 |
| aplikace | MPH |
| Rozlišení | 240×400 |
| Složení | OLED |
| Jas | 210 |
| CR | 2000:1 |
| Barvy | 65K/262K |
| Podsvícení | self |
| Rozhraní | CPU/RGB/SPI |
| značka panelu | LG Display |
| panelový model | LH300WQ1-ED01 |
| typ panelu | AM-OLED , OLED |
| velikost panelu | 3.0 inch |
| rozlišení | 240(RGB)×400 , WQVGA |
| aktivní oblast | 38.88×64.8 mm |
| obrys | 44×74.6 mm |
| povrch | Hard coating |
| jas | 210 cd/m² (Typ.) |
| kontrastní poměr | 2000 : 1 (Min.) |
| zobrazit barvy | 65K/262K , CIE193185% |
| úhel pohledu | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | 8/9/16/18-bit 6800/8080 parallel, 6/16/18-bit RGB, SPI, 40 pins |
| vstupní napětí | 2.8/2.8/3.7V (Typ.)(VDD/VCC/VBATT) |
| aplikace | MPH |
