| PartNumber | LH350H01-FD01 |
| Značka | LG Display |
| Velikost | 3.5 |
| aplikace | MPH |
| Rozlišení | 320×480 |
| Složení | LCM |
| Jas | 450 |
| CR | 150:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | LG Display |
| panelový model | LH350H01-FD01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×480 , HVGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 49.92×74.88 mm |
| obrys | 55.14×82.84×1.85 mm |
| povrch | |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 150:1 (Typ.)(Transmissive) |
| zobrazit barvy | 16.7M (8-bit), CIE193150% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 60/60/60/45 (Typ.)(CR≥5)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 20 pins |
| vstupní napětí | 3.0/5.672/1.8V (Typ.)(VDDC/VDDA/LO_VCC) |
| aplikace | MPH |
