| PartNumber | LH530WX1-SH02 |
| Značka | LG Display |
| Velikost | 5.3 |
| aplikace | MPH |
| Rozlišení | 720×1280 |
| Složení | CELL |
| Jas | 0 |
| CR | 900:1 |
| Barvy | |
| Podsvícení | No B/L |
| Rozhraní | |
| značka panelu | LG Display |
| panelový model | LH530WX1-SH02 |
| typ panelu | a-Si TFT-LCD , CELL |
| velikost panelu | 5.3 inch |
| rozlišení | 720(RGB)×1280 , WXGA |
| zobrazovací mód | AH3-IPS, Normally Black, Transmissive |
| aktivní oblast | 65.45×116.35 mm |
| obrys | 68.048×123.652×0.3 mm |
| povrch | |
| hloubka skla | 0.15+0.15 mm |
| propustnost | 3.5% (Typ.)(with Polarizer) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | , CIE193174% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| řidič ic | COG Suggest HX8394-A01, NT33520, NT35521, OTM1283A, OTM1288A |
| aplikace | MPH |
