| PartNumber | LQ035JC211 |
| Značka | Innolux |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | |
| CR | 400:1 |
| Barvy | |
| Podsvícení | |
| Rozhraní | |
| značka panelu | ChiHsin |
| panelový model | LQ035JC211 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 70.08×52.56 mm |
| obrys | 76.9×63.9 mm |
| povrch | |
| jas | |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | , CIE193160% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | |
| rohs: | |
| aplikace | DSC |
| LQ035JC211 | Innolux | 3.5 | 320×240 |
| LQ035LC111 | Innolux | 3.5 | 320×240 |
| LQ035NC211 | Innolux | 3.5 | 320×240 |
| LQ035Q1DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q1DH02 | SHARP | 3.5 | 320×240 |
| LQ035Q3DG01 | SHARP | 3.5 | 320×240 |
| LQ035Q7DB03F | SHARP | 3.5 | 240×320 |
| LQ035Q7DB05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH05 | SHARP | 3.5 | 240×320 |
| LQ035Q7DH06 | SHARP | 3.5 | 240×320 |
| A015AN02 V5 | AUO | 1.46 | 280×220 |
| A024CN02 VL | AUO | 2.4 | 480×234 |
| A027DN03 V7 | AUO | 2.7 | 320×240 |
| A027DN03 V8 | AUO | 2.7 | 320×240 |
| A030DN01 V9 | AUO | 3.0 | 320×240 |
| A035VL01 V6 | AUO | 3.5 | 800×480 |
| DLC0350CZG-T-2 | Other | 3.5 | 320×240 |
| LTV350QV-F07 | Samsung | 3.5 | 320×240 |
| TD024THEB2 | TPO | 2.4 | 480×240 |
| TD030WHEA1 | TPO | 3.0 | 320×240 |
