| PartNumber | LQ035NC211 |
| Značka | Innolux |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 200 |
| CR | 400:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Parallel/Serial |
| značka panelu | ChiHsin |
| panelový model | LQ035NC211 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 70.08×52.56 mm |
| obrys | 76.9×63.9×4.56 mm |
| povrch | Antiglare (Haze 20%) |
| jas | 200 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 16.7M , CIE193160% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 6S1PWLEDWithout Driver |
| signálové rozhraní | Digital RGB (8/24-bit) + SPI, CCIR601/656, 54 pins |
| vstupní napětí | 3.3V (Typ.)(VCC) |
| aplikace | DSC |
