| PartNumber | LQ035Q7DB04 |
| Značka | SHARP |
| Velikost | 3.5 |
| aplikace | |
| Rozlišení | 240×320 |
| Složení | LCM |
| Jas | 50 |
| CR | 70:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ035Q7DB04 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 53.64×71.52 mm |
| obrys | 65×85×4.8 mm |
| povrch | Hard coating (3H) |
| jas | 50 cd/m² (Typ.) |
| kontrastní poměr | 70:1 (Typ.)(Transmissive)8:1 (Typ.)(Reflective) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 60/100 (Typ.)(Tr/Td) |
| úhel pohledu | 40/40/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 6-bit), 50 pins |
| vstupní napětí | 5.0/3.3/15.0/-10.0V (Typ.)(VSGA/VSHD/VDD/VEE) |
