| PartNumber | LQ050T3GG01 |
| Značka | SHARP |
| Velikost | 5.0 |
| aplikace | PDVD |
| Rozlišení | 400×234 |
| Složení | LCM |
| Jas | 350 |
| CR | 60:1 |
| Barvy | Full color |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | SHARP |
| panelový model | LQ050T3GG01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 400(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 111.6×62.9 mm |
| obrys | 127.7×80.8×7.6 mm |
| povrch | |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 60:1 (Min.) |
| zobrazit barvy | Full color |
| Doba odezvy | 30/50 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/40/65 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 32 pins |
| vstupní napětí | 5.3/10.9/13.0/-10.0V (Typ.)(VSH/VCC/VGH/VGL) |
| aplikace | PDVD |
