| PartNumber | LQ050T5DG01 |
| Značka | SHARP |
| Velikost | 5.0 |
| aplikace | CNS |
| Rozlišení | 400×240 |
| Složení | LCM |
| Jas | 600 |
| CR | 800:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ050T5DG01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 400(RGB)×240 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 108×64.8 mm |
| obrys | 120.6×75.2×16.8 mm |
| povrch | Antiglare |
| jas | 600 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 262K (6-bit), CIE193150% |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥5)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4S2PWLEDWithout Driver |
| signálové rozhraní | CMOS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3/9.0V (Typ.)(VCC/VDC) |
| aplikace | CNS |
