| PartNumber | LQ050T5DW02 |
| Značka | SHARP |
| Velikost | 5.0 |
| aplikace | CNS |
| Rozlišení | 400×240 |
| Složení | LCM |
| Jas | |
| CR | 1200:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ050T5DW02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.0 inch |
| rozlišení | 400×240(RGB) , WQVGA |
| zobrazovací mód | ASV, Normally Black, Transmissive |
| aktivní oblast | 108×64.8 mm |
| povrch | |
| jas | |
| kontrastní poměr | 1200:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 15/10 (Typ.)(Tr/Td) |
| úhel pohledu | 45/45/45/45 (Typ.)(CR≥200)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDWithout Driver |
| signálové rozhraní | CMOS (1 ch, 6-bit), 40 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | CNS |
