| PartNumber | LQ057AC111 |
| Značka | Other |
| Velikost | 5.7 |
| aplikace | IA |
| Rozlišení | 320×240 |
| Složení | LCM |
| Jas | 350 |
| CR | 200:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Parallel/Serial |
| značka panelu | CHILIN |
| panelový model | LQ057AC111 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.7 inch |
| rozlišení | 320(RGB)×240 , QVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 115.2×86.4 mm |
| obrys | 126×101.55 mm |
| povrch | Antiglare |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 200:1 (Typ.) |
| zobrazit barvy | 16.7M |
| Doba odezvy | 15/35 (Typ.)(Tr/Td) |
| úhel pohledu | 65/65/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S7PWLEDWithout Driver |
| signálové rozhraní | Digital RGB (8/24-bit), CCIR601/656, 50 pins |
| vstupní napětí | 3.3/5.0V (Typ.)(VDD/AVDD) |
| aplikace | IA |
