| PartNumber | LQ084S3LG02 |
| Značka | SHARP |
| Velikost | 8.4 |
| aplikace | IA |
| Rozlišení | 800×600 |
| Složení | LCM |
| Jas | 350 |
| CR | 450:1 |
| Barvy | 262K/16.2M |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | SHARP |
| panelový model | LQ084S3LG02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 8.4 inch |
| rozlišení | 800(RGB)×600 , SVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 170.4×127.8 mm |
| obrys | 199.5×149.5×12 mm |
| povrch | Antiglare, Hard coating (2H) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 450:1 (Typ.) |
| zobrazit barvy | 262K/16.2M (6-bit / 6-bit + FRC) |
| Doba odezvy | 35 (Typ.)(Tr+Td) |
| úhel pohledu | 65/65/60/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 2 pcsCCFL |
| signálové rozhraní | LVDS (1 ch, 6/8-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
| AA084SA01 | Mitsubishi | 8.4 | 800×600 |
| LQ084S1DH10 | SHARP | 8.4 | 800×600 |
| LQ084S3DG01 | SHARP | 8.4 | 800×600 |
| LQ084S3LG01 | SHARP | 8.4 | 800×600 |
| LQ084S3LG02 | SHARP | 8.4 | 800×600 |
| LQ084S3LG03 | SHARP | 8.4 | 800×600 |
| LQ084V1DG21 | SHARP | 8.4 | 640×480 |
| LQ084V1DG21E | SHARP | 8.4 | 640×480 |
| LQ084V1DG22 | SHARP | 8.4 | 640×480 |
| NL8060BC21-11F | NLT | 8.4 | 800×600 |
| AA104VC04 | Mitsubishi | 10.4 | 640×480 |
| EL640.400-CB1 | Lumineq | 9.1 | 640×400 |
| G170ETN01.0 | AUO | 17.0 | 1280×1024 |
| KCB104VG2CG-G20 | Kyocera | 10.4 | 640×480 |
| KL6448USTS-FFW | Kyocera | 6.9 | 640×480 |
| LJ640U35 | SHARP | 8.9 | 640×400 |
| LM32K101 | SHARP | 4.7 | 320×240 |
| LQ104V1LG81 | SHARP | 10.4 | 640×480 |
| NL6448BC26-09C | NLT | 8.4 | 640×480 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
