| PartNumber | LQ101K5DZ01 |
| Značka | SHARP |
| Velikost | 10.1 |
| aplikace | CNS |
| Rozlišení | 1280×422 |
| Složení | LCM |
| Jas | 500 |
| CR | 2000:1 |
| Barvy | 16.2M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | SHARP |
| panelový model | LQ101K5DZ01 1 Compatible model |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 10.1 inch |
| rozlišení | 1280(RGB)×422 |
| zobrazovací mód | ASV, Normally Black, Transmissive |
| aktivní oblast | 242.88×80.07 mm |
| obrys | 259.7×96.5 mm |
| povrch | Antiglare, Reflection 1.5% (Typ.) |
| jas | 500 cd/m² (Typ.) |
| kontrastní poměr | 2000:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC) |
| Doba odezvy | 15/5 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | WLEDEmbedded (LED Driver) |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit), 68 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | CNS |
