| PartNumber | LS024Q8UC02 |
| Značka | SHARP |
| Velikost | 2.4 |
| aplikace | MPH |
| Rozlišení | 240×320 |
| Složení | CELL |
| Jas | 0 |
| CR | 90:1 |
| Barvy | 65K |
| Podsvícení | No B/L |
| Rozhraní | CPU |
| značka panelu | SHARP |
| panelový model | LS024Q8UC02 |
| typ panelu | CG-Silicon , CELL |
| velikost panelu | 2.4 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | TN, Normally White, Transflective |
| aktivní oblast | 36.72×48.96 mm |
| obrys | 41.7×83.65×1.75 mm |
| povrch | Hard coating |
| propustnost | 8.2% (Typ.)(with Polarizer) |
| kontrastní poměr | 90:1 (Typ.)(Transmissive)7:1 (Typ.)(Reflective) |
| zobrazit barvy | 65K , CIE193159% |
| Doba odezvy | 60 (Typ.)(Tr+Td) |
| úhel pohledu | 35/35/40/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | CPU, 36 pins |
| vstupní napětí | 2.85V (Typ.) |
| aplikace | MPH |
| 24QVW2H | SII | 2.4 | 240×320 |
| LS024J3LX01 | SHARP | 2.4 | 320×480 |
| LS024Q3UX05 | SHARP | 2.4 | 240×320 |
| LS024Q3UX12(G) | SHARP | 2.4 | 320×240 |
| LS024Q8DD92 | SHARP | 2.4 | 240×320 |
| LS024Q8UC02 | SHARP | 2.4 | 240×320 |
| RGS24128064WW001 | RiTdisplay | 2.4 | 128×64 |
| RX024A-03 | ROGIN | 2.4 | 480×234 |
| TM024HDH36 | Tianma | 2.4 | 240×320 |
| UG-2864ASGPG01 | WiseChip | 2.4 | 128×64 |
| ACX465AKM-7 | JDI | 5.9 | 1080×1920 |
| AMDM001 | Samsung | 2.6 | 240×400 |
| AMS369FG07-002 | Samsung | 3.7 | 480×800 |
| CLAF055LA41 TXX | CPT | 5.5 | 540×960 |
| HSD015F4N2-B | HannStar | 1.5 | 128×128 |
| LH470WX6-SJ11 | LG Display | 4.7 | 750×1334 |
| LS026B8PX04 | SHARP | 2.6 | 240×400 |
| LS047T1SC01K | SHARP | 4.7 | 1080×1920 |
| LTP283QV-F04 | Samsung | 2.8 | 240×320 |
| TM023KDH60 | Tianma | 2.3 | 320×240 |
