| PartNumber | PA035XSL |
| Značka | E Ink |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 320×234 |
| Složení | LCM |
| Jas | 250 |
| CR | 350:1 |
| Barvy | Full color |
| Podsvícení | WLED |
| Rozhraní | Analog |
| značka panelu | PVI |
| panelový model | PA035XSL |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 71.6×52.65 mm |
| obrys | 83.5×63.1×3.9 mm |
| povrch | Antiglare |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | Full color |
| Doba odezvy | 15/25 (Typ.)(Tr/Td) |
| úhel pohledu | 50/50/15/35 (Typ.)(CR≥10)(L/R/U/D) |
| typ lampy | 3S2PWLEDWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 30 pins |
| vstupní napětí | 3.3/3.3/5.0/17.0/-12.0V (Typ.)(VCC/VDD/AVDD/VGH/VGL) |
| aplikace | DSC |
