| PartNumber | LTM170EI-A01 |
| Značka | Samsung |
| Velikost | 17.0 |
| aplikace | DMPC |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 250 |
| CR | 350:1 |
| Barvy | 16.2M |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | SAMSUNG |
| panelový model | LTM170EI-A01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 17.0 inch |
| rozlišení | 1280(RGB)×1024 , SXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 337.92×270.336 mm |
| obrys | 383.5×298.6×19.5 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193165% |
| Doba odezvy | 5/20 (Typ.)(Tr/Td) |
| úhel pohledu | 75/75/65/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 pcsCCFLEmbedded (Inverter) |
| signálové rozhraní | Analog RGB, 27 pins |
| aplikace | DMPC |
| LTM170E8-L02 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L03 | Samsung | 17.0 | 1280×1024 |
| LTM170E8-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EI-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170ET01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-A01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L01 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L21 | Samsung | 17.0 | 1280×1024 |
| LTM170EU-L31 | Samsung | 17.0 | 1280×1024 |
| LTM170W1-L01 | Samsung | 17.0 | 1280×768 |
| CLAA170ES01E | CPT | 17.0 | 1280×1024 |
| LM150X08-A4K3 | LG Display | 15.0 | 1024×768 |
| LM190WX1-TLA1 | LG Display | 19.0 | 1440×900 |
| LM201W01-B6K1 | LG Display | 20.1 | 1680×1050 |
| LM270WF5-SLA1 | LG Display | 27.0 | 1920×1080 |
| LM300W01-STA1 | LG Display | 30.0 | 2560×1600 |
| M170EG01 V9 | AUO | 17.0 | 1280×1024 |
| M185BGE-L10 | Innolux | 18.5 | 1366×768 |
| M220Z1-L01 | Innolux | 22.0 | 1680×1050 |
| MT190AW01 V.C | Innolux | 19.0 | 1440×900 |
