| PartNumber | LTN070NL01 |
| Značka | Samsung |
| Velikost | 7.0 |
| aplikace | PAD |
| Rozlišení | 1024×600 |
| Složení | LCM |
| Jas | 400 |
| CR | 800:1 |
| Barvy | 16.2M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | SAMSUNG |
| panelový model | LTN070NL01 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 7.0 inch |
| rozlišení | 1024(RGB)×600 , WSVGA |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 153.6×90 mm |
| obrys | 164.05×100.86 mm |
| povrch | Glare (Haze 0%), Hard coating (3H) |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.2M (6-bit + FRC), CIE193150% |
| Doba odezvy | 30 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6S4PWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (1 ch, 8-bit), 31 pins |
| vstupní napětí | 3.7V (Typ.) |
| aplikace | PAD |
