| PartNumber | MT185GW01 V.4 |
| Značka | Innolux |
| Velikost | 18.5 |
| aplikace | DMPC |
| Rozlišení | 1366×768 |
| Složení | LCM |
| Jas | 250 |
| CR | 1000:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | CHIMEI INNOLUX |
| panelový model | MT185GW01 V.4 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 18.5 inch |
| rozlišení | 1366(RGB)×768 , WXGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 409.8×230.4 mm |
| obrys | 430.37×254.6×10.25 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | 16.7M (6-bit + Hi-FRC), CIE193170% |
| Doba odezvy | 1.5/3.5 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 14S6PWLEDWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 30 pins |
| vstupní napětí | 5.0V (Typ.) |
| aplikace | DMPC |
| CLAA185WA02 | CPT | 18.5 | 1366×768 |
| CLAA185WA03 | CPT | 18.5 | 1366×768 |
| G185XW01 V1 | AUO | 18.5 | 1366×768 |
| LM185WH1-TLC5 | LG Display | 18.5 | 1366×768 |
| M185BGE-L22 | Innolux | 18.5 | 1366×768 |
| M185BGE-P02 | Innolux | 18.5 | 1366×768 |
| M185XTN01.2 | AUO | 18.5 | 1366×768 |
| MT185GW01 V.0 | Innolux | 18.5 | 1366×768 |
| MT185GW01 V.4 | Innolux | 18.5 | 1366×768 |
| MT185WHM-N20 | BOE | 18.5 | 1366×768 |
| CLAA170EA07 | CPT | 17.0 | 1280×1024 |
| LM185WH2-TLD1 | LG Display | 18.5 | 1366×768 |
| LM201U05-SLA1 | LG Display | 20.1 | 1600×1200 |
| LM220WE1-TLD2 | LG Display | 22.0 | 1680×1050 |
| LM220WE1-TLE2 | LG Display | 22.0 | 1680×1050 |
| LM230WF3-S2E4 | LG Display | 23.0 | 1920×1080 |
| LTM190EX-L31 | Samsung | 19.0 | 1280×1024 |
| LTM230HP07 | Samsung | 23.0 | 1920×1080 |
| M185BGE-L2U | Innolux | 18.5 | 1366×768 |
| M236HJK-L3B | Innolux | 23.6 | 1920×1080 |
