| PartNumber | NL10276BC30-39 |
| Značka | NLT |
| Velikost | 15.0 |
| aplikace | IA |
| Rozlišení | 1024×768 |
| Složení | LCM |
| Jas | 270 |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | NEC |
| panelový model | NL10276BC30-39 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 15.0 inch |
| rozlišení | 1024(RGB)×768 , XGA |
| zobrazovací mód | UA-SFT, Normally Black, Transmissive |
| aktivní oblast | 304.128×228.096 mm |
| obrys | 326.5×253.5×12.2 mm |
| povrch | Antiglare, Hard coating (3H) |
| jas | 270 cd/m² (Typ.) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193172% |
| Doba odezvy | 14/11 (Typ.)(Tr/Td) |
| úhel pohledu | 88/88/88/88 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 6 stringsWLEDWithout Driver |
| signálové rozhraní | LVDS (1 ch, 8-bit), 20 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | IA |
| NL10276AC30-07 | NLT | 15.0 | 1024×768 |
| NL10276AC30-42C | NLT | 15.0 | 1024×768 |
| NL10276BC12-02 | NLT | 6.3 | 1024×768 |
| NL10276BC20-37 | NLT | 10.4 | 1024×768 |
| NL10276BC24-13 | NLT | 12.1 | 1024×768 |
| NL10276BC28-21A | NLT | 14.1 | 1024×768 |
| NL10276BC30-17 | NLT | 15.0 | 1024×768 |
| NL10276BC30-18L | NLT | 15.0 | 1024×768 |
| NL10276BC30-33D | NLT | 15.0 | 1024×768 |
| NL10276BC30-39 | NLT | 15.0 | 1024×768 |
| DLC1040ABG-2 | Other | 10.4 | 800×600 |
| G133I1-L02 | Innolux | 13.3 | 1280×800 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
| HLD0909-020010 | Hosiden | 9.0 | 640×480 |
| LM-GK53-22NTX | SANYO | 13.6 | 1024×768 |
| LM7MS623 | SHARP | 6.5 | 640×240 |
| LQ150X1LGB1 | SHARP | 15.0 | 1024×768 |
| LTA090B230F | TOSHIBA | 9.0 | 536×328 |
| NL8048AC19-13 | NLT | 7.0 | 800×480 |
| TX18D11VM1CAA | KOE | 7.0 | 800×480 |
