| PartNumber | R213T3-L02 |
| Značka | Innolux |
| Velikost | 21.3 |
| aplikace | MD |
| Rozlišení | 2560×2048 |
| Složení | LCM |
| Jas | |
| CR | 850:1 |
| Barvy | Grayscale |
| Podsvícení | CCFL |
| Rozhraní | LVDS |
| značka panelu | CMO |
| panelový model | R213T3-L02 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 21.3 inch |
| rozlišení | 2560(LCR)×2048 , QSXGA |
| zobrazovací mód | DD-IPS, Normally Black, Transmissive |
| aktivní oblast | 422.4×337.92 mm |
| obrys | 459.8×375.3 mm |
| povrch | |
| jas | |
| kontrastní poměr | 850:1 (Typ.) |
| zobrazit barvy | Grayscale (8-bit) |
| Doba odezvy | 18/18 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥20)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | CCFLEmbedded (Inverter) |
| signálové rozhraní | LVDS (4 ch, 8-bit), 73 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | MD |
