| PartNumber | P080KDZ-3Z1 |
| Značka | Innolux |
| Velikost | 8.0 |
| aplikace | PAD |
| Rozlišení | 1200×1920 |
| Složení | CELL |
| Jas | 0 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | MIPI |
| značka panelu | INNOLUX |
| panelový model | P080KDZ-3Z1 |
| typ panelu | a-Si TFT-LCD , CELL |
| velikost panelu | 8.0 inch |
| rozlišení | 1200(RGB)×1920 , WUXGA |
| zobrazovací mód | IPS, Normally Black, Transmissive |
| aktivní oblast | 107.64×172.224 mm |
| obrys | 112.64×181.8 mm |
| povrch | Hard coating |
| hloubka skla | 0.40+0.40 mm |
| propustnost | 3.85% (Typ.)(with Polarizer) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193160% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | MIPI (4 data lanes), 40 pins |
| vstupní napětí | 3.3/10.0/21.0/-7.0V (Typ.)(VDD/AVDD/VGH/VGL) |
| aplikace | PAD |
