| PartNumber | LSL080AL02-002 |
| Značka | Samsung |
| Velikost | 8.0 |
| aplikace | PAD |
| Rozlišení | 800×1280 |
| Složení | CELL |
| Jas | 0 |
| CR | 900:1 |
| Barvy | 16.7M |
| Podsvícení | No B/L |
| Rozhraní | MIPI |
| značka panelu | SAMSUNG |
| panelový model | LSL080AL02-002 |
| typ panelu | a-Si TFT-LCD , CELL |
| velikost panelu | 8.0 inch |
| rozlišení | 800(RGB)×1280 , WXGA |
| zobrazovací mód | PLS, Normally Black, Transmissive |
| aktivní oblast | 107.64×172.224 mm |
| obrys | 112.64×181.824×0.69 mm |
| povrch | Glare (Haze 0%), Hard coating |
| hloubka skla | 0.20+0.20 mm |
| propustnost | 6.6% (Typ.)(with Polarizer) |
| kontrastní poměr | 900:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 16 (Typ.)(Tr+Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| signálové rozhraní | MIPI (4 data lanes), 34 pins |
| vstupní napětí | 1.8/3.3V (Typ.)(DVDD/PVDD) |
| aplikace | PAD |
| AV080WSM-NW0 | BOE | 8.0 | 1024×600 |
| BP080WX7-100 | BOE | 8.0 | 1280×800 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080XA01BW | CPT | 8.0 | 1024×768 |
| LA080WV3-SD01 | LG Display | 8.0 | 800×480 |
| LM64C219 | SHARP | 8.0 | 640×480 |
| LQ080Y5DW30 | SHARP | 8.0 | 800×480 |
| LSL080AL02-002 | Samsung | 8.0 | 800×1280 |
| LSL080AL02-B01 | Samsung | 8.0 | 800×1280 |
| TX20D28VM2BAB | KOE | 8.0 | 800×480 |
| B116XAN01.0 | AUO | 11.6 | 1366×768 |
| HE101NA-02C | Innolux | 10.1 | 1280×800 |
| HT121WX2-211 | HYDIS | 12.1 | 1280×800 |
| HV089WU1-1E0 | HYDIS | 8.9 | 1920×1200 |
| HV121WX6-110 | HYDIS | 12.1 | 1280×800 |
| LD089WU1-SM01 | LG Display | 8.9 | 1920×1200 |
| LT070ME05000 | JDI | 7.0 | 1200×1920 |
| LTL101AL06-003 | Samsung | 10.1 | 1280×800 |
| TV096WXM-NS0 | BOE | 9.6 | 800×1280 |
| VVX10T022N00 | Panasonic | 10.1 | 2560×1600 |
