| PartNumber | PD035OX4 |
| Značka | E Ink |
| Velikost | 3.5 |
| aplikace | DSC |
| Rozlišení | 320×234 |
| Složení | LCM |
| Jas | 250 |
| CR | 400:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | Parallel/Serial |
| značka panelu | PVI |
| panelový model | PD035OX4 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 320(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 71.6×52.65 mm |
| obrys | 84.03×65.24×3.73 mm |
| povrch | Antiglare |
| jas | 250 cd/m² (Typ.) |
| kontrastní poměr | 400:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit) |
| Doba odezvy | 15/25 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/35/45 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S2PWLEDWithout Driver |
| signálové rozhraní | Digital RGB (8/24-bit), CCIR601/656, 60 pins |
| vstupní napětí | 3.3/3.3/5.0/15/-15V (Typ.)(VCC/VDD1/VDD2/VGH/VEE) |
| aplikace | DSC |
