| PartNumber | PD035VX2 |
| Značka | E Ink |
| Velikost | 3.5 |
| aplikace | PND |
| Rozlišení | 640×480 |
| Složení | LCM |
| Jas | 450 |
| CR | 600:1 |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | PVI |
| panelový model | PD035VX2 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 640(RGB)×480 , VGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 72×52.56 mm |
| obrys | 84.03×65.24 mm |
| povrch | Antiglare |
| jas | 450 cd/m² (Typ.) |
| kontrastní poměr | 600:1 (Typ.) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 15/25 (Typ.)(Tr/Td) |
| úhel pohledu | 75/75/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 3S2PWLEDWithout Driver |
| signálové rozhraní | TTL (1 ch, 6-bit), 50 pins |
| vstupní napětí | 3.3/3.3/10/17/-10V (Typ.)(VCC/VDD/VDD1/VCG/VEE) |
| aplikace | PND |
