| PartNumber | NL2432DR22-11B |
| Značka | NLT |
| Velikost | 3.5 |
| aplikace | PDA |
| Rozlišení | 240×320 |
| Složení | LCM |
| Jas | 50 |
| CR | |
| Barvy | 262K |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | NEC |
| panelový model | NL2432DR22-11B |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 3.5 inch |
| rozlišení | 240(RGB)×320 , QVGA |
| zobrazovací mód | TN, Normally White, Reflective |
| aktivní oblast | 53.64×71.52 mm |
| obrys | 66.2×91×4.7 mm |
| povrch | Hard coating (3H) |
| jas | 50 cd/m² (Typ.) |
| kontrastní poměr | 10/10(Reflective) |
| zobrazit barvy | 262K (6-bit) |
| Doba odezvy | 15/17 (Typ.)(Tr/Td) |
| úhel pohledu | |
| typ lampy | 2S2PWLED |
| signálové rozhraní | CMOS (1 ch, 6-bit), 45 pins |
| vstupní napětí | 3.0/5.25/15.0/-15.0V (Typ.)(VCC/VDD/VGON/VGOFF) |
| aplikace | PDA |
| 990000738A | Innolux | 3.5 | 320×240 |
| A035QN02 VE | AUO | 3.5 | 320×240 |
| DLC0350SZG | Other | 3.5 | 480×640 |
| LH350H01-FD01 | LG Display | 3.5 | 320×480 |
| LQ035NC111 | Innolux | 3.5 | 320×240 |
| LQ035Q7DB02R | SHARP | 3.5 | 240×320 |
| LTV350QV-F04 | Samsung | 3.5 | 320×240 |
| NL2432DR22-02B | NLT | 3.5 | 240×320 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| PT035TN01 V.6 | Innolux | 3.5 | 320×240 |
| ACX502BMU-7 | SONY | 3.5 | 240×320 |
| LS037V7DD05 | SHARP | 3.7 | 480×640 |
| LTP500GV-F01 | Samsung | 5.0 | 480×640 |
| NL2432DR22-11B | NLT | 3.5 | 240×320 |
| NL2432HC22-41K | NLT | 3.5 | 240×320 |
| NL2432HC22-50B | NLT | 3.5 | 240×320 |
| NL4864HL11-01B | NLT | 3.5 | 480×640 |
| TD035STEB2 | TPO | 3.5 | 240×320 |
| TD035STED7 | TPO | 3.5 | 240×320 |
| TM038QV-67A03 | SANYO | 3.8 | 320×240 |
