| PartNumber | R190EFE-L51 |
| Značka | Innolux |
| Velikost | 19.0 |
| aplikace | MD |
| Rozlišení | 1280×1024 |
| Složení | LCM |
| Jas | 1400 |
| CR | 1000:1 |
| Barvy | Grayscale |
| Podsvícení | WLED |
| Rozhraní | LVDS |
| značka panelu | INNOLUX |
| panelový model | R190EFE-L51 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 19.0 inch |
| rozlišení | 1280(LCR)×1024 , SXGA |
| zobrazovací mód | DD-IPS, Normally Black, Transmissive |
| aktivní oblast | 376.32×301.06 mm |
| obrys | 396×324×26.1 mm |
| povrch | Antiglare (Haze 25%), Hard coating (3H) |
| jas | 1400 cd/m² (Typ.) |
| kontrastní poměr | 1000:1 (Typ.) |
| zobrazit barvy | Grayscale (8-bit) |
| Doba odezvy | 15/15 (Typ.)(Tr/Td) |
| úhel pohledu | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 4 stringsWLEDEmbedded (LED Driver) |
| signálové rozhraní | LVDS (2 ch, 8-bit), 30 pins |
| vstupní napětí | 12.0V (Typ.) |
| aplikace | MD |
