| PartNumber | TFD60W12 |
| Značka | TOSHIBA |
| Velikost | 6.0 |
| aplikace | IA |
| Rozlišení | 320×234 |
| Složení | LCM |
| Jas | 280 |
| CR | 80:1 |
| Barvy | Full color |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | TOSHIBA |
| panelový model | TFD60W12 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 6.0 inch |
| rozlišení | 320(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 121.92×89.154 mm |
| obrys | 144×109.4 mm |
| povrch | |
| jas | 280 cd/m² (Typ.) |
| kontrastní poměr | 80:1 (Typ.) |
| zobrazit barvy | Full color |
| Doba odezvy | 70/40 (Max.)(Tr/Td) |
| úhel pohledu | 45/45/45/15 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB, 24 pins |
| vstupní napětí | 5.0/13.0/23.0/-5.0V (Typ.)(VDD/VBB/VGG/VEE) |
| aplikace | IA |
