| PartNumber | TFD65W46 |
| Značka | TOSHIBA |
| Velikost | 6.5 |
| aplikace | CNS |
| Rozlišení | 480×234 |
| Složení | LCM |
| Jas | 400 |
| CR | 250:1 |
| Barvy | Full color |
| Podsvícení | CCFL |
| Rozhraní | Analog |
| značka panelu | Toshiba Matsushita |
| panelový model | TFD65W46 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 6.5 inch |
| rozlišení | 480(RGB)×234 |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 144.72×77.103 mm |
| povrch | Antiglare |
| jas | 400 cd/m² (Typ.) |
| kontrastní poměr | 250:1 (Typ.) |
| zobrazit barvy | Full color |
| Doba odezvy | 100/50 (Max.)(Tr/Td) |
| úhel pohledu | 55/55/60/30 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 1 pcsCCFLWithout Driver |
| signálové rozhraní | TFT Specific Analog RGB |
| rohs: | |
| aplikace | CNS |
