| PartNumber | TM055XDHP10 |
| Značka | Tianma |
| Velikost | 5.5 |
| aplikace | MPH |
| Rozlišení | 540×960 |
| Složení | LCM |
| Jas | 350 |
| CR | 800:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | MIPI |
| značka panelu | TIANMA |
| panelový model | TM055XDHP10 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 5.5 inch |
| rozlišení | 540(RGB)×960 , qHD |
| zobrazovací mód | FFS, Normally Black, Transmissive |
| aktivní oblast | 68.04×120.96 mm |
| obrys | 72.14×130.86×1.95 mm |
| povrch | Antiglare (Haze 42%) |
| jas | 350 cd/m² (Typ.) |
| kontrastní poměr | 800:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193170% |
| Doba odezvy | 25 (Typ.)(Tr+Td) |
| úhel pohledu | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 80Hz |
| typ lampy | 5S2PWLEDWithout Driver |
| signálové rozhraní | MIPI (2 data lanes), 30 pins |
| vstupní napětí | 1.8/2.8V (Typ.)(IOVCC/VCC) |
| aplikace | MPH |
