| PartNumber | TS40WD2B-03 |
| Značka | Other |
| Velikost | 4.0 |
| aplikace | PND |
| Rozlišení | 480×272 |
| Složení | LCM |
| Jas | 320 |
| CR | 350:1 |
| Barvy | 16.7M |
| Podsvícení | WLED |
| Rozhraní | TTL |
| značka panelu | TopSun |
| panelový model | TS40WD2B-03 |
| typ panelu | a-Si TFT-LCD , LCM |
| velikost panelu | 4.0 inch |
| rozlišení | 480(RGB)×272 , WQVGA |
| zobrazovací mód | TN, Normally White, Transmissive |
| aktivní oblast | 87.84×49.776 mm |
| obrys | 98.3×62.6 mm |
| povrch | |
| jas | 320 cd/m² (Typ.) |
| kontrastní poměr | 350:1 (Typ.) |
| zobrazit barvy | 16.7M (8-bit), CIE193154% |
| Doba odezvy | 10/15 (Typ.)(Tr/Td) |
| úhel pohledu | 60/60/50/55 (Typ.)(CR≥10)(L/R/U/D) |
| frekvence | 60Hz |
| typ lampy | 8S1PWLEDWithout Driver |
| signálové rozhraní | Parallel RGB (1 ch, 8-bit), 50 pins |
| vstupní napětí | 3.3V (Typ.) |
| aplikace | PND |
| AMS397GE66 | Samsung | 4.0 | 480×800 |
| LB040Q02-TD01 | LG Display | 4.0 | 320×240 |
| LB040Q02-TD05 | LG Display | 4.0 | 320×240 |
| LS040T3SW01 | SHARP | 4.0 | 540×960 |
| LT040MDU4100 | TOSHIBA | 4.0 | 480×854 |
| LTE400WQ-E01 | Samsung | 4.0 | 480×272 |
| PA040XS1 | E Ink | 4.0 | 320×234 |
| PD040QT2 | E Ink | 4.0 | 320×240 |
| TS40WD2B-03 | Other | 4.0 | 480×272 |
| TX10D121VM0AAA | JDI | 4.0 | 480×800 |
| 35HVF0H | SII | 3.5 | 320×480 |
| ET043001DM6 | EDT | 4.3 | 480×272 |
| LB043WQ2-TD08 | LG Display | 4.3 | 480×272 |
| LB043WQ3-TD03 | LG Display | 4.3 | 480×272 |
| LMS430HF17-002 | Samsung | 4.3 | 480×272 |
| LMS430HF26 | Samsung | 4.3 | 480×272 |
| LMS500HF01 | Samsung | 5.0 | 480×272 |
| LQ036T1DG01 | SHARP | 3.6 | 272×480 |
| LQ043T1DH01 | SHARP | 4.3 | 480×272 |
| LTE480WV-F01 | Samsung | 4.8 | 800×480 |
